Application
1.Low current Signal connection for battery pack, distribution box, motor controller and other equipment. 2. On board charger, PDU, air conditioner, PTC, DC / DC, slow charging interface, distribution box and other equipment
Electrical performance
| Rated Current | 5A~80A |
| Rated Voitage | 300V~1000V |
| Insulation Resistance | 5000MΩ(@25℃ 40%-60%RH) |
| Test Voitage | 1500~3000VDC |
Mechanical performance
| Minimum Mating Cycles | 500cycles |
| Wire Range | 0.25mm²~16mm² |
Environment performance
| IP Degree | IP68(mated) |
| Operation Temperature | -40℃~125℃ |
| Salt Spray Resistance | 48H |
Reference standard
| USCAR-2 |
| USCAR-37 |
| RoHS |
| MIL-C-26482 |
