Application
Electric energy transmission: battery to inverter, battery tobattery.
Electrical performance
| Rated Current | 200A |
| Rated Voitage | 1000V |
| Insulation Resistance | 5000MΩ MIN( Drying) 200MΩ MIN(RH 95%) |
| Test Voitage | 500V AC |
Mechanical performance
| Minimum Mating Cycles | 100 |
| Wire Range | 25mm²/70mm² |
Environment performance
| IP Degree | IP55/IP68 |
| Operation Temperature | -40℃~125℃ |
| Salt Spray Resistance | 48H (mating state） |
Reference standard
| USCAR-2 |
| Rohs |
